6 Pair 24AWG Telephone Cable - PE89 Direct Burial (per foot)
$0.92
Reference#: 68309
Item#: BC1891224BKGN
Item#: BC1891224BKGN
Description
UTILITY
Our 6-Pair 24AWG PE89 Direct Burial Telephone Cable is suitable for direct underground burial, an underground conduit system or as aerial telephone cable between poles. This direct bury phone cable provides outstanding protection against the elements. It features dual insulation, with an inner layer of foamed polyethylene surrounded by a solid polyethylene skin color coded according to telephone industry standards. An ETPR compound completely coats each insulated conductor and fills the space between conductors.
AVAILABILITY
With its single-jacket, filled design, this direct burial telephone cable is ideal for outside plant applications where equipment must stand up to tough environmental conditions. It is gel-filled to protect against water and moisture penetration.
·Core Construction: Solid, annealed copper, size 24 AWG
·Core Wrap: Non-hygroscopic dielectric tape applied longitudinally with an overlap
·Aluminum Shield: Corrugated copolymer coated 0.008” aluminum tape applied longitudinally with overlap. The sheath interfaces have been flooded with an adhesive water-blocking compound
Get free shipping on qualifying orders, with delivery usually taking two to five business days. Quicker shipping options are also available.
VALUE
Our high-tech cable reeling machinery allows us to cut this cable to length so we can better serve your needs, whether you need 75 feet, a 3,500-foot run or some other quantity. Order only what you need, with no waste. Quantity discounts are available for this cable too.
Our 6-Pair 24AWG PE89 Direct Burial Telephone Cable is suitable for direct underground burial, an underground conduit system or as aerial telephone cable between poles. This direct bury phone cable provides outstanding protection against the elements. It features dual insulation, with an inner layer of foamed polyethylene surrounded by a solid polyethylene skin color coded according to telephone industry standards. An ETPR compound completely coats each insulated conductor and fills the space between conductors.
AVAILABILITY
With its single-jacket, filled design, this direct burial telephone cable is ideal for outside plant applications where equipment must stand up to tough environmental conditions. It is gel-filled to protect against water and moisture penetration.
·Core Construction: Solid, annealed copper, size 24 AWG
·Core Wrap: Non-hygroscopic dielectric tape applied longitudinally with an overlap
·Aluminum Shield: Corrugated copolymer coated 0.008” aluminum tape applied longitudinally with overlap. The sheath interfaces have been flooded with an adhesive water-blocking compound
Get free shipping on qualifying orders, with delivery usually taking two to five business days. Quicker shipping options are also available.
VALUE
Our high-tech cable reeling machinery allows us to cut this cable to length so we can better serve your needs, whether you need 75 feet, a 3,500-foot run or some other quantity. Order only what you need, with no waste. Quantity discounts are available for this cable too.
Specification
Core Construction: Solid, annealed copper; size 24 AWG
Insulation: Dual insulation consisting of an inner layer of foamed polyethylene surrounded by a solid polyethylene skin, color-coded in accordance with telephone industry standards
Twisted Pairs: Insulated conductors are twisted into pairs with varying lay lengths to minimize crosstalk
Core Assembly: 25 pairs and less: pairs are assembled together in a single group More than 25 pairs: pairs are arranged in groups, each group having a color coded unit binder.
Core Wrap: Non-hygroscopic dielectric tape applied longitudinally with an overlap
Aluminum Shield: Corrugated, co-polymer coated, 0.008" aluminum tape applied longitudinally with an overlap The sheath interfaces are flooded with an adhesive water-blocking compound
Jacket: Black, linear low density polyethylene Application(s):
Compliance: Rural Development Utility Program(RDUP) 7 CFR 1755.890 (RUS PE-89)
Insulation: Dual insulation consisting of an inner layer of foamed polyethylene surrounded by a solid polyethylene skin, color-coded in accordance with telephone industry standards
Twisted Pairs: Insulated conductors are twisted into pairs with varying lay lengths to minimize crosstalk
Core Assembly: 25 pairs and less: pairs are assembled together in a single group More than 25 pairs: pairs are arranged in groups, each group having a color coded unit binder.
Core Wrap: Non-hygroscopic dielectric tape applied longitudinally with an overlap
Aluminum Shield: Corrugated, co-polymer coated, 0.008" aluminum tape applied longitudinally with an overlap The sheath interfaces are flooded with an adhesive water-blocking compound
Jacket: Black, linear low density polyethylene Application(s):
Compliance: Rural Development Utility Program(RDUP) 7 CFR 1755.890 (RUS PE-89)
