HS-12 Thermal Stripper for Both Single and Ribbon Fiber Cable
$599.95
Reference#: 76509
Item#: FF-HS-12
Item#: FF-HS-12
Description
The FiberFox HS-12 newly developed hand-held thermal stripper is rugged and durable, yet small in size and light weight. Designed to strip the jacket of single fiber and ribbon cable up to 12 fibers (fiber holders sold separately), it offers extreme convenience under any tough environment. Benefits include fast heating time of 4 seconds and approximately 500 cycles with a fully charged battery. So easy to use that anyone can do clear stripping with near zero failure.
Fiber Holders Sold Separately:
- FH-250 250um Fiber Holder
- FH-900 900um Fiber Holder
- Call for other sizes
* Note: The HS-12 is a direct replacement for the T-1000
Features
- HS-12 Long-lasting Thermal Stripper for both ribbon fiber and single fiber cable
- World’s fastest heating time of 4sec
- Long lasting battery: Approximately. 500 times with a full charged battery by simple operation
Specification
| Fiber Material | Silica glass |
|---|---|
| Coating Material | UV cured resin |
| Coating Thickness | “Single fiber: 0.25~0.4mm 2 to 12 Ribbon fiber: 0.3~0.4mm” |
| Cladding Diameter | 125μm |
| Coating Removal Length | max 30mm |
| Heating Mode | Normal mode / Power save mode |
| Temperature Settings | Normal mode: approx. 80℃, 95℃, 110℃, 130℃ Power save mode: approx. 70℃, 80℃, 95℃, 110℃ |
| Fiber Holder Type | FH-2, FH-4, FH-6, FH-8, FH-10, FH-12, FH-250, FH-900, FH-U (Universal Holder both for 250μm and 900μm) |
| Power Supply Method | 1) AC drive: AC100~240V, 50/60Hz 2) DIN port: DC 12V power supplied from fusion splicer |
| Operating Condition | Temperature: 0℃~40℃ / Humidity: 0%~95% |
| Applicable Fiber Type | Single fiber: 250μm, 900μm, 3.0mm fiber cable and flat cable Ribbon fiber: 2 to 12 ribbon fiber cable |
| Heating Time | Approx. 4~5sec at normal mode Approx. 5~6sec at save mode |
| Battery Capacity | Approx. 500 stripping with 12 ribbon fiber with a full charged battery |
